DK交流无刷伺服电机
概要

DK系列交流伺服电机广泛应用于机床、机械手臂、纺织机械、塑料机械、印染机械、印刷机械、建筑机械、建材机械,港口提升运输机械,木材加工机械,人造板制造生产线,各种工业机械手,自动化流水线,自动化仓储系统,冶金机械雷达、火炮等领域。DK系列交流伺服电动机由定子、转子、高精度反馈元件(如:光电编码器、旋转变压器等)组成。采用高性能稀土永磁材料形成气隙磁场,采用无机壳定子铁芯,温度梯度大,散热效率高。

特征

·结构紧凑,功率密度高
·转子惯量小,响应速度快
·超高内禀矫顽力稀土永磁材料;抗去磁能力强
·几乎在整个转速范围内可恒转矩输出
·低速转矩脉动小,平衡精度高,高速运行平稳
·噪音低,振动小
·全密封设计
·性能价格比高

应用领域

广泛应用于机床、机械手臂、纺织机械、塑料机械、印染机械、印刷机械、建筑机械、建材机械,港口提升运输机械,木材加工机械,人造板制造生产线,各种工业机械手,自动化流水线,自动化仓储系统,冶金机械雷达、火炮等领域

技术概述
3相220V 3相380V
型号 框架
mm
额定转速
rpm
静转矩
Nm
相电流
A
重量
kg
DK6011-8AF31 40 3000 0.12 1.09 0.27
DK6013-8AF31 40 3000 0.21 1.40 0.35
DK6014-8AF31 40 3000 0.28 1.35 0.73
DK6015-8AF31 40 3000 0.41 1.44 0.62
DK6021-8AF31 60 3000 0.6 1.93 1.2
DK6023-8AF31 60 3000 0.8 2.87 1.5
DK6025-8AF31 60 3000 1.6 3.8 1.8
DK6031-8AF31 80 3000 3.2 4.3 2.8
DK6032-8AF31 80 3000 4.3 6.3 3.6
DK6040-6AC31 96 2000 1.6 2.1 3.7
DK6040-6AF31 96 3000 1.6 2.6 3.7
DK6040-6AK31 96 6000 1.6 5.2 3.7
DK6041-6AC31 96 2000 2.5 2.8 4.3
DK6041-6AF31 96 3000 2.5 4.2 4.3
DK6041-6AK31 96 6000 2.5 8.5 4.3
DK6042-6AC31 96 2000 3.2 3.0 5.0
DK6042-6AF31 96 3000 3.2 4.5 5.0
DK6042-6AK31 96 6000 3.2 9.0 5.0
DK6051-6AC31 110 2000 2.0 2.4 4.5
DK6051-6AF31 110 3000 2.0 3.5 4.5
DK6052-6AC31 110 2000 3.0 3.0 5.5
DK6052-6AF31 110 3000 3.0 4.5 5.5
DK6053-6AC31 110 2000 4.0 4.0 6.5
DK6053-6AF31 110 3000 4.0 5.0 6.5
DK6054-6AC31 110 2000 5.0 5.0 7.5
DK6054-6AF31 110 3000 5.0 6.0 7.5
DK6055-6AC31 110 2000 6.0 6.0 8.5
DK6055-6AF31 110 3000 6.0 8.0 8.5
DK6060-6AC31 126 2000 3.0 2.5 8.5
DK6060-6AF31 126 3000 3.0 3.8 8.5
DK6061-6AC31 126 2000 6.0 5.5 10.6
DK6061-6AF31 126 3000 6.0 8.3 10.6
DK6062-6AC31 126 2000 7.5 6.2 12.8
DK6062-6AF31 126 3000 7.5 9.3 12.8
DK6063-6AC31 126 2000 11.0 9.0 14.5
DK6063-6AF31 126 3000 11.0 13.5 14.5
DK6064-6AC31 126 2000 4.5 3.7 9.5
DK6064-6AF31 126 3000 4.5 5.5 9.5
DK6065-6AC31 126 2000 15.0 12.3 17.8
DK6065-6AF31 126 3000 15.0 18.3 17.8
DK6070-6AC31 126 2000 3.0 2.5 8.5
DK6070-6AF31 126 3000 3.0 3.8 8.5
DK6071-6AC31 126 2000 6.0 4.88 10.6
DK6071-6AF31 126 3000 6.0 7.3 10.6
DK6072-6AC31 126 2000 7.5 6.2 12.8
DK6072-6AF31 126 3000 7.5 9.3 12.8
DK6073-6AC31 126 2000 11 9.0 14.5
DK6073-6AF31 126 3000 11 13.5 14.5
DK6074-6AC31 126 2000 4.5 3.7 9.5
DK6074-6AF31 126 3000 4.5 5.5 9.5
DK6075-6AC31 126 2000 15 12.3 17.8
DK6075-6AF31 126 3000 15 18.3 17.8
DK6080-6AC31 155 2000 16 16 16.5
DK6080-6AF31 155 3000 16 24 16.5
DK6081-6AA31 155 1200 21 12.2 19.5
DK6081-6AC31 155 2000 21 20 19.5
DK6081-6AF31 155 3000 21 30 19.5
DK6083-6AA31 155 1200 27 16.2 22.5
DK6083-6AC31 155 2000 27 26.5 22.5
DK6085-6AA31 155 1200 33 19.8 25.5
DK6085-6AC31 155 2000 33 33 25.5
DK6087-6AA31 155 1200 37 22.2 28.5
DK6087-6AC31 155 2000 37 37 28.5
DK6089-6AA31 155 1200 42 25.2 31.5
DK6089-6AC31 155 2000 42 42 31.5
DK6091-8AB31 180 1500 22.5 13.7 20.7
DK6091-8AC31 180 2000 22.5 18.2 20.7
DK6091-8AF31 180 3000 22.5 27.3 20.7
DK6093-8AB31 180 1500 34 21 23.3
DK6093-8AC31 180 2000 34 28 23.3
DK6093-8AF31 180 3000 34 42 23.3
DK6095-8AB31 180 1500 41 24.2 27.5
DK6095-8AC31 180 2000 41 32.5 27.5
DK6095-8AF31 180 3000 41 48.8 27.5
DK6097-8AB31 180 1500 56 33 36.7
DK6097-8AC31 180 2000 56 44 36.7
DK6097-8AF31 180 3000 56 66 36.7
DK6100-8AC31 192 2000 18 17.5 21
DK6100-8AF31 192 3000 18 24.5 21
DK6101-8AA31 192 1200 27 15.3 26
DK6101-8AC31 192 2000 27 24.5 26
DK6101-8AF31 192 3000 27 35 26
DK6103-8AA31 192 1200 36 20.4 30
DK6103-8AC31 192 2000 36 35 30
DK6105-8AA31 192 1200 45 27 34
DK6105-8AC31 192 2000 45 45 34
DK6107-8AA31 192 1200 55 33 38
DK6107-8AC31 192 2000 55 55 38
DK6109-8AA31 192 1200 70 42 45
DK6109-8AC31 192 2000 70 70 45
型号 框架
mm
额定转速
rpm
静转矩
Nm
相电流
A
重量
kg
DK6025-8AF61 60 3000 1.6 1.8 1.8
DK6031-8AF61 80 3000 3.2 1.9 2.8
DK6032-8AF61 80 3000 4.3 3.9 3.6
DK6040-6AC61 96 2000 1.6 0.9 3.7
DK6040-6AF61 96 3000 1.6 1.4 3.7
DK6041-6AC61 96 2000 2.5 1.4 4.3
DK6041-6AF61 96 3000 2.5 2.2 4.3
DK6042-6AC61 96 2000 3.2 1.9 5
DK6042-6AF61 96 3000 3.2 2.8 5
DK6060-6AC61 126 2000 3 1.5 8.5
DK6060-6AF61 126 3000 3 2.3 8.5
DK6061-6AC61 126 2000 6 3.0 10.6
DK6061-6AF61 126 3000 6 4.5 10.6
DK6062-6AC61 126 2000 7.5 3.8 12.8
DK6062-6AF61 126 3000 7.5 5.7 12.8
DK6063-6AC61 126 2000 11 5.6 14.5
DK6063-6AF61 126 3000 11 8.3 14.5
DK6064-6AC61 126 2000 4.5 2.2 9
DK6064-6AF61 126 3000 4.5 3.2 9
DK6065-6AC61 126 2000 15 6.2 17.8
DK6065-6AF61 126 3000 15 9.1 17.8
DK6070-6AC61 126 2000 3 1.5 8.5
DK6070-6AF61 126 3000 3 2.3 8.5
DK6071-6AC61 126 2000 6 3.0 10.6
DK6071-6AF61 126 3000 6 4.5 10.6
DK6072-6AC61 126 2000 7.5 3.8 12.8
DK6072-6AF61 126 3000 7.5 5.7 12.8
DK6073-6AC61 126 2000 11 5.6 14.5
DK6073-6AF61 126 3000 11 8.3 14.5
DK6074-6AC61 126 2000 4.5 2.2 9
DK6074-6AF61 126 3000 4.5 3.2 9
DK6075-6AC61 126 2000 15 7.6 17.8
DK6075-6AF61 126 3000 15 11.3 17.8
DK6080-6AC61 155 2000 16 6.8 16.5
DK6080-6AF61 155 3000 16 10.5 16.5
DK6081-6AA61 155 1200 21 6.1 19.5
DK6081-6AC61 155 2000 21 10 19.5
DK6081-6AF61 155 3000 21 15 19.5
DK6083-6AA61 155 1200 27 8.1 22.5
DK6083-6AC61 155 2000 27 13.3 22.5
DK6083-6AF61 155 3000 27 20 22.5
DK6085-6AA61 155 1200 33 9.9 25.5
DK6085-6AC61 155 2000 33 16.5 25.5
DK6085-6AF61 155 3000 33 24.8 25.5
DK6087-6AA61 155 1200 37 11.1 28.5
DK6087-6AC61 155 2000 37 18.5 28.5
DK6087-6AF61 155 3000 37 27.8 28.5
DK6089-6AA61 155 1200 42 12.6 31.5
DK6089-6AC61 155 2000 42 21 31.5
DK6089-6AF61 155 3000 42 31.5 31.5
DK6091-8AB61 180 1500 22.5 6.7 20.7
DK6091-8AC61 180 2000 22.5 8.9 20.7
DK6091-8AF61 180 3000 22.5 13.4 20.7
DK6093-8AB61 180 1500 34 10.3 23.3
DK6093-8AC61 180 2000 34 13.7 23.3
DK6093-8AF61 180 3000 34 20.6 23.3
DK6095-8AB61 180 1500 41 12.3 27.5
DK6095-8AC61 180 2000 41 16.4 27.5
DK6095-8AF61 180 3000 41 24.6 27.5
DK6097-8AB61 180 1500 56 16.9 36.7
DK6097-8AC61 180 2000 56 22.5 36.7
DK6097-8AF61 180 3000 56 33.8 36.7
DK6100-8AA61 192 1200 18 4.7 21
DK6100-8AB61 192 1500 18 5.9 21
DK6100-8AC61 192 2000 18 7.8 21
DK6100-8AF61 192 3000 18 11.7 21
DK6101-8AA61 192 1200 27 7.0 26
DK6101-8AB61 192 1500 27 8.8 26
DK6101-8AC61 192 2000 27 11.7 26
DK6101-8AF61 192 3000 27 17.5 26
DK6103-8AA61 192 1200 36 9.4 30
DK6103-8AB61 192 1500 36 11.8 30
DK6103-8AC61 192 2000 36 15.7 30
DK6103-8AF61 192 3000 36 23.5 30
DK6105-8AA61 192 1200 45 11.7 34
DK6105-8AB61 192 1500 45 14.5 34
DK6105-8AC61 192 2000 45 19.5 34
DK6105-8AF61 192 3000 45 30.6 34
DK6107-8AA61 192 1200 55 14.3 38
DK6107-8AB61 192 1500 55 17.9 38
DK6107-8AC61 192 2000 55 23.8 38
DK6109-8AA61 192 1200 70 18.5 45
DK6109-8AB61 192 1500 70 23.1 45
DK6109-8AC61 192 2000 70 28.2 45
DK61011-8AA61 192 1200 90 23.8 57
DK61011-8AB61 192 1500 90 29.7 57
DK61011-8AC61 192 2000 90 36.3 57
